Detailed Product Description I. Definition

Industrial video endoscope (also known as view mirror) is a branch of nondestructive testing, and is also a special detection technique. Suitable for high temperature, toxic, nuclear radiation and the human eye cannot directly observe the site inspection and observation (such as: automobile, automobile casting, engine, machine parts, pipes, pressure vessels, power system, wind power generation, chemical, mechanical equipment, railway locomotives, etc.) can be realized without disassembly or in nondestructive testing destroy the assembly and equipment stop operation, can greatly improve the safety and efficiency of detection equipment.

II. Technical Advantages

T7-21 series industrial endoscopes are equipped with independent intellectual property rights, collecting high-tech, machine, electricity and other high-tech industrial video detection instruments. The detection instrument consists of a color-specific display, strand detection line and so on. Specific technical advantages are as follows:
1. Wide detection range: adapting to inspection items such as pipelines and containers, using a wide-angle probe to make the inspection process easy, and it is especially suitable for video inspection of gas-tight pipelines, chemical pipelines, water-cooled walls, containers, and air separation pipelines.
2. Long detection distance: configure a custom length inspection line. In the case of only one hand hole, the detection range can be completely covered, so that the operator does not need to conduct a large number of pipeline welding and recovery after the inspection is completed.
3. Due to the adoption of LED cold light source lighting scheme, the maintenance cost is extremely low and the light source has a lifetime of more than 10,000 hours.
4. All T7-21 series products adopt electronic technology, and the inspection line is strong and durable, with few points of failure.
5. If the equipment fails, the supplier can provide the backup machine in time so as not to affect the normal construction period.


III. Features

1. AC and DC power supply, comes with high-performance lithium battery, the site does not need to use AC, can be detected at any time.
2.7-inch controller is integrated with the cable tray. It is more convenient to use and can be operated independently.
3. IP65 splash-proof design, special requirements can be customized IP68 waterproof level.
4. Light weight, easy to use and easy to carry.


IV. Product Details


1. T7-21 miniature color camera probe (patent product), probe diameter 21mm, field of view angle 175 °,
