URNDT 1717V Wireless Portable Flat Panel Detector for 160KV DR system

Product Details:

Place of Origin:China
Brand Name:URNDT
Model Number:1717V

Payment & Shipping Terms:

Minimum Order Quantity:1 set
Packaging Details:ABS
Delivery Time:4-8 weeks
Payment Terms:TT
Detailed Product Description
Features:
- Wireless cassette detector per ISO 4090, fits in bucky
- 139 pm pixel pitch, with 16 bit ADC for more image details
- Stable iSync+ Automatic Exposure Detection (AED)
- Dual band (2.4 and 5 GHz) wireless support with easy sharing
- Long battery life and smart workflow
- Direct deposition Csl for better image quality with lower dose

Summary:
1717V is a smart 17x17-inch wireless, cassette-sized FPD for radiographic imaging. It features reliable AED, dependable wireless performance, and a long battery life. The Mars 1717V supports a fast work flow, and is the optimal choice for both retrofit and new DR system solutions.

Technical Specifications:
Detector Technology: Amorphous Silicon
Scintillator: Csl
Active Area (inch): 17x 17
Pixel Matrix: 3072 x3072
Pixel Pitch (pm): 139
Spatial Resolution (Ip/mm): 3.6
AD Conversion (bit): 16
Battery Autonomy (h): 8
WIFI: 2.4G and 5G, IEEE802.11 a/b/g/n/ac
Trigger Mode: AED (Optional) / Software
Full Image Time (s): 5
Dimensions (mm3): 460x460 x 15
Weight (kg): 4.3
Static Loading: 150kg Uniformly
Ingress Protection: IPX1
Operating Temperature (°C): 5~35
Storage & Transport Temperature with Package (°C): -20 ~ 55
Operating Humidity (% RH): 10 ~ 90 (Non-Condensing)
Storage & Transport Humidity with Package (% RH): 5 * 95 (Non-Condensing)
