Detailed Product Description
Application:
IDEA-IT2D is widely used in the industries as military, aviation, metallurgy and automobile etc, it is able to detect and access the flaw quickly and accurately in aircraft component, such as structural alloy, airframe, engine vane, wheel hubs, landing gear, rivet inner & outer crack, aluminum surface, fuselage wing joint etc.
Specification：
Basic Parameter
L X W X H ： 250 MM x 190 MM x 90 MM
Screen： Resolution 640 X 480 5.7’ TFT Color LCD
Weight： 2 Kg (Including Battery)
Interfaces： LEMO-6 LEMO-15 DB-25
Lithium: 12V 3000mAH
Power Supply： 110V/60hz 220V/50hz
Operating Temperature： -10° ～ 50°Ｃ
System Parameter
CPU： ARM11 Embedded 32dot 500M Processor
Operating System： liunx 2.6
RAM： 256M
SD CARD memory capacity： 8G
USB interface： 12M/S, USB-2.0（Host/Slave）
Encoder： 1024 Pulse/Round Resolution:0.1mm
Operation Language： English/Chinese
LCD Luminance： 1-8 Grade
Inspection Parameter
Independent Detection Frequency: 2 in total
Frequency Range： 10 Hz～10 MHz，Step 1 Hz
Gain： 0 dB～99 dB，Step 0.1 dB
Phase： 0～359°，Step 1 Deg
Intelligent Mixing Unit： 1 in total
Probe Driver： Vpp=1～16
Probe Impedance： 50Ω 100Ω
X&Y Gain Control: Y/X = 0.1—10
Calibration Curve： Amplitude Phase Equivalent
Display Mode：Impedance, time base, rectangular coordinates, polar coordinates
Scanning Speed： 1-100 Grade
Center coordinates: X Y adjustable
Digital Signal
Digital Filtering：HPF（0Hz～2000Hz）、LPF（0Hz～2000Hz）
Filtering Points：1-1024
Broadband： 100Hz～10MHz
A/D Velocity： 16bit 100M
Min-Senstivity: 1mV
Real-Time Average：2 4 8 16 32
Automatic Balance：Digital Electronic Balance
Alarm Set
Type: Phase/Non-continuous Windows and Door Frame
Gate： A/B
Amplitude Value： 10%-120%
Sound： On/Off
Peripheral： Photoelectric I/O
Parameter Storage
Detection Save,Delete,Edit：above 10000 sets
Real-time signal preservation,playback,analysis,save and print： 8G/24Hour
Testing Pics： Above 10000 PCS
USB Storage: Available
Print： Online/Wireless
Help System
Automatically display date,time and battery capacity
Easy operation,real-time screen point-out
Online hotkey,graphics,words help
